Complete Kit Ready to Fit - Standard Kit includes 2 x L 1500 x D 310mm shelves & 1 x L 1500 x D 210mm on the near side | 2 x L 1000mm x D310mm & 1 x L 1000 x D210mm Bulkhead shelf
(Optional 410mm depth bottom shelf. This will incur an additional £100.00 ex vat per shelf to the cost)
The standard 1500mm length profile shelf design has a high back support with a low front 30mm profile. There is an option to change to a low back support profile which is ideal if you wish to have easier access to items, tools from the near side opening door. In addition there is also a U profile design that is preferred for racking along the bulkhead but also useful for loose objects like pipes etc. We will confirm if these requirements are preferred during the ordering process.
The 310mm deep shelf is ideal for most storage boxes, tool cases and containers and is our most popular shelf depth. Customers sometimes choose a 410mm depth shelf for the bottom shelf for larger containers.
Fits any height van.
Once an order is placed Vantainer will make contact to confirm the internal cargo height from the floor to flat part of the ceiling. Vantainer machine the support struts prior to sending out the kit. Please note : There is approximately 60-100mm of adjustability on the telescopic adaptors.
Van racking Kit Contents:
3 - anodised aluminium struts with ceiling quick release telescopic adaptors, and floor plug adaptors.
3 - Heavy duty Velcro self-adhesive fleece (for ceiling)
3 - Ceiling pad with adaptor cone
3 - Aluminium two part floor adaptor - includes floor fixings
6 - Traverse bar 3 x 1500mm with end caps | 3 x 1000mm bar with end caps
6 - 'L' profile shelf 2 x L 1500mm x 310mm | 1 x L 1500 x D 210mm | 2 x L1000 x 310mm | 1 x L1000 x D210mm
12 - Triangular shelf support brackets with screws.
8 - Pole adaptor brackets with bolts.
8 - End panels
1 - Tool kit - Allen Keys
Maximum load capacity per shelf 75 kg
NOTE: If the vehicle has a ceiling lining, this must be temporarily removed to allow 40mm location holes and then easily replaced.
